YEM1L-100~630 Leakage Type MCCB
YEM1L-100~630 Leakage Type  Molded Case Circuit Breaker 3P 4P 125a Power Mccb With Earth Leakage Protection
  • Model Name: YEM1L-100~630 Leakage Type MCCB
  • Rated Current: 63,125,250,400,630,800,1250,1600
  • Rated Voltage :230,415,500,690
  • Poles:2P,3P,4P
  • Rated Insulation Voltage:1000V
  • Standard:IEC60947-2
Get A Free Quote
PDF Download
  • Description
  • Tags

  • 1.Product Information

    Name Details Name Details
    Enterprise code Shanghai Yuhuang Electric Co.,Ltd N Pole shape Four poles products' N polar form:
    A type: N polar do not install over-current release, and N polar electrifies all the time. At the same time, N polar does not open and close together with other three.
    B type: N polar do not install over-current release, and N polar opens and closes together with other three polars.
    Product category Moulded case circuit breaker Release form V type, U type, W type, VA type
    Design code 1 Alarm module None=No alarm module, I=Alarm and trip, II=Alarm and don’t trip
    Product code Moulded case earth leakage circuit breaker Operation type None=Manual direct operation, P=Electric operation, Z=Manual manipulation
    Current frame 100(125), 225(250), 400, 630 Wiring type None=Front wiring, R=Back board wiring, PR=Plug-in
    Breaking capacity L=Economical type, M=Standard type, H=High score type Rated current 16A~630A
    Pole 3P, 4P Use No None=Power distribution protection, 2=Protect motor
    Part No 300=No part (Please see the release part No. table)

    2.Technical parameter

    Type YEM1L-100 YEM1L-225 YEM1L-400 YEM1L-630
    Current frame (A) 100 225 400 630
    Pole 3 / 4 3 / 4 3 / 4 3 / 4
    Rated current In (A) 16/20/25/32/40/50/63/80/100 100/125/140/160/180/200/225 225/250/315/350/400 400/500/630
    Rated insulation voltage U (V) AC800
    Rated impulse withstand voltage Uimp (V) 8000
    Rated working voltage Ue (V) 50/60Hz AC400
    Arc-over distance (mm) 50(0) +50(0) 100(0) 100(0)
    Class of rated ultimate short-circuit breaking capacity M / H / L
    50 / 85 / 50 50 / 85 / 50 65 / 100 / 65 65 / 100 / 65
    Rated service short-circuit breaking capacity Ics (kA) 35 / 50 / 35 35 / 50 / 35 42 / 65 / 42 42 / 65 / 42
    Rated residual operating current I△n (A) AC type residual current protection:
    U type release, non delay: 0.03/0.1/0.3/0.5
    V type release, non delay, adjustable delay: 0.1/0.3/0.5
    W type release, non delay, adjustable delay: 0.3/1/3/10
    A type residual current protection: VA type release, non delay, adjustable delay 0.1/0.3/0.5
    Rated residual non-operating current I△no(A): 1/2 I△n
    Rated residual short-circuit connect (breaking) capacity I△m (kA): 1/4 Icu
    Use category: A
    Electrical life (times): 8000 / 8000 / 7500 / 7500
    Mechanical life (without maintenance) 20000 20000 10000 10000
    Mechanical life (with maintenance) 40000 40000 20000 20000
    Outline dimension (mm) W:92 × L:150 × H:92 W:107 × L:165 × H:90 W:150 × L:257 × H:106.5 W:210 × L:280 × H:115.5



    3.Better Performances in Demanding Duties

    YEM1L series moulded case earth leakage circuit breaker is applied in the circuit of AC 50/60HZ,.It is used to transfer infrequently and protect motor. Circuit breaker has over-load,short circuit and under-voltage protection function so that protects the circuit and power supply device from being damaged. At the same time,it can provide indirect contact protection for people, and it can also provide protection for fire rise which may be caused long-term ground faults that cannot be detected by over-current protection. When other protective devices fail, the leakage current circuit breaker YEM1L with a rated residual current of 30mA can directly act as an additional protection.



    4.Product advantage
    1.This circuit breaker can be equipped with leakage alarm and non tripping module to avoid heavy losses caused by power failure.
    2.This circuit breaker has the features of small volume,high breaking ability,short arc and anti-vibration.
    3.Circuit breaker can be installed in a vertical way.
    4.The circuit breaker can not be poured into the line,that is only the 1、3、5 is allowed to connect the power line,and the 2、4、6 is connected to the load line.
    5.Circuit breaker has isolation function.
